Series BMPS11

Features Design :Pneumatically actuated pinch valve
Structure code :S1
Sealing principle: Eleastic lip seal
Mounting position :Any
Type of mounting : In-line installation
Direction of ow : Reversible
Valve function : 2/2 way,normally open
Reset method : Rebound resilience
Nominal pressure : PN10
Sleeve feature : Replaceable
Connection : G,BSP,NPT female thread
Contact
  • Product Description
  • Download

Operating and environmental condition
Ambient temperature [°C]-5.....+60
Storage temperature [°C]6......+20
Medium pressure [bar]0......6
Pressure diference [bar]2.5......3
Optimum control pressureMedium pressure+Pressure diference
Compressed air toISO 8573-1:2010


Material
HousingPOM,Wrought aluminum alloy, Wrought stainless steel
SocketPOM,Wrought aluminum alloy, Wrought stainless steel
Seal or sleeve Anti-abrasive natural rubber,EPDM,NBR,......

size

Dimensions
DNDiGLDTCVol.l Weight
(mm)(mm)(mm)(mm)(mm)(mm)

KG
10103/8''844712G 1/8''0.040.2
15151/2''995214G 1/8''0.050.3
20203/4''1196117G 1/8''0.070.4
25251''1406720G 1/8''0.850.5
32321 1/4''1538020G 1/4''0.150.8
40401 1/2''1649320G 1/4''0.251.2
50502''18911625G 1/4''0.361.8


 Note:

1.Anti-abrasive natural rubber,EPDM sleeve are widely used, others on request,please refer sleeve technical sheet.

2.Other size or dimension on request.

3.Body and socket material:natural white POM,black POM,Wrought aluminum alloy,stainless steel,others on request.

4.Connection are G,BSP,NPT female thread,others on request.


  • Series BMPS11 PDF
  • Series BMPS11 DWG
